Bronze

ISO 9001 Manufactured and Full ANSI Rated

Most typical cast eductors made by others in the industry meet only nominal pressure ratings. Jacoby Tarbox Eductors and Jet Pumps are designed and produced to meet rigorous ASME/ANSI specifications. JT eductors and jet pumps offer ratings about 30% higher than most competitors.

Bronze Rating: 500 psig @ 100 F

  • Model HG 1/2" BRZ
    1/2" Model HG in Bronze Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Steam / Air Motive Pressure: 20-150 PSIG Pressure Recovery:...

    $259.00
  • Model HL 1/2" BRZ
    1/2" Model HL in Bronze Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Liquid Motive Pressure: 15-250 PSIG Pressure...

    $259.00
  • Model ML 1/2" BRZ
    1/2" Model ML in Bronze Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Liquid Motive Pressure: 15-250 PSIG Pressure...

    $259.00
  • Model SG 1/2" BRZ
    1/2" Model SG in Bronze Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure...

    $259.00
  • Model SL 1/2" BRZ
    1/2" Model SL in Bronze Motive Connection: 1/4" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery:...

    $259.00
  • Model HG 3/4" BRZ
    3/4" Model HG in Bronze Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 40-50% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft...

    $299.00
  • Model HL 3/4" BRZ
    3/4" Model HL in Bronze Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 40-50% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft...

    $299.00
  • Model ML 3/4" BRZ
    3/4" Model ML in Bronze Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 30-35% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft...

    $299.00
  • Model SG 3/4" BRZ
    3/4" Model SG in Bronze Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure Recovery: 15-20% Maximum Suction Lift: -20ft. Maximum Required NPSH: 13ft...

    $299.00
  • Model SL 3/4" BRZ
    3/4" Model SL in Bronze Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 10-15% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft...

    $299.00
  • Model HG 1" BRZ
    1" Model HG in Bronze Motive: Steam / Air Motive Pressure: 20-150 PSIG Pressure Recovery: 30-35% Maximum Suction Lift: -20ft. Maximum Required NPSH: 13ft...

    $339.00
  • Model HL 1" BRZ
    1" Model HL in Bronze Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 40-50% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft...

    $339.00
  • Model ML 1" BRZ
    1" Model ML in Bronze Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 30-35% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft...

    $339.00
  • Model SG 1" BRZ
    1" Model SG in Bronze Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure Recovery: 15-20% Maximum Suction Lift: -20ft. Maximum Required NPSH: 13ft...

    $339.00
  • Model SL 1" BRZ
    1" Model SL in Bronze Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 10-15% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft...

    $339.00
  • Model ULJ 1" BRZ
    1" Model ULJ in Bronze Maximum Temperature Rise: 200°F Maximum Flow Heated: 700 GPM Steam Pressure Range: 0-150 PSIG

    $320.00
  • Model HG 1-1/4" BRZ
    1-1/4" Model HG in Bronze Motive: Steam / Air Motive Pressure: 20-150 PSIG Pressure Recovery: 30-35% Maximum Suction Lift: -20ft. Maximum Required NPSH: 13ft...

    $399.00
  • Model HL 1-1/4" BRZ
    1-1/4" Model HL in Bronze Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 40-50% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft...

    $399.00
  • Model ML 1-1/4" BRZ
    1-1/4" Model ML in Bronze Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 30-35% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft...

    $399.00
  • Model SG 1-1/4" BRZ
    1-1/4" Model SG in Bronze Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure Recovery: 15-20% Maximum Suction Lift: -20ft. Maximum Required NPSH: 13ft...

    $399.00
