316SS

ISO 9001 Manufactured and Full ANSI Rated

Most typical cast eductors made by others in the industry meet only nominal pressure ratings. Jacoby Tarbox Eductors and Jet Pumps are designed and produced to meet rigorous ASME/ANSI specifications. JT eductors and jet pumps offer ratings about 30% higher than most competitors.

316SS Rating: 720 psig @ 100 F

  • Model HG 1/2" 316SS
    1/2" Model HG in 316SS Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Steam / Air Motive Pressure: 20-150 PSIG Pressure Recovery:...

    $375.00
  • Model HL 1/2" 316SS
    1/2" Model HL in 316SS Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Liquid Motive Pressure: 15-250 PSIG Pressure...

    $375.00
  • Model SG 1/2" 316SS
    1/2" Model SG in 316SS Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure...

    $375.00
  • Model SL 1/2" 316SS
    1/2" Model SL in 316SS Motive Connection: 1/4" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery:...

    $375.00
  • Model HG 3/4" 316SS
    3/4" Model HG in 316SS Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 40-50% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft...

    $495.00
  • Model HL 3/4" 316SS
    3/4" Model HL in 316SS Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 40-50% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft...

    $495.00
  • Model SG 3/4" 316SS
    3/4" Model SG in 316SS Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure Recovery: 15-20% Maximum Suction Lift: -20ft. Maximum Required NPSH: 13ft...

    $495.00
  • Model SL 3/4" 316SS
    3/4" Model SL in 316SS Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 10-15% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft...

    $495.00
  • Model HG 1" 316SS
    1" Model HG in 316SS Motive: Steam / Air Motive Pressure: 20-150 PSIG Pressure Recovery: 30-35% Maximum Suction Lift: -20ft. Maximum Required NPSH: 13ft...

    $525.00
  • Model HL 1" 316SS
    1" Model HL in 316SS Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 40-50% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft...

    $525.00
  • Model ML 1" 316SS
    1" Model ML in 316SS Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 30-35% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft...

    $525.00
  • Model SG 1" 316SS
    1" Model SG in 316SS Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure Recovery: 15-20% Maximum Suction Lift: -20ft. Maximum Required NPSH: 13ft...

    $525.00
  • Model SL 1" 316SS
    1" Model SL in 316SS Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 10-15% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft...

    $525.00
  • Model ULJ 1" 316SS
    1" Model ULJ in 316SS Maximum Temperature Rise: 200°F Maximum Flow Heated: 700 GPM Steam Pressure Range: 0-150 PSIG

    $525.00
  • Model HG 1-1/4" 316SS
    1-1/4" Model HG in 316SS Motive: Steam / Air Motive Pressure: 20-150 PSIG Pressure Recovery: 30-35% Maximum Suction Lift: -20ft. Maximum Required NPSH: 13ft...

    $695.00
  • Model HL 1-1/4" 316SS
    1-1/4" Model HL in 316SS Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 40-50% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft...

    $695.00
  • Model ML 1-1/4" 316SS
    1-1/4" Model ML in 316SS Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 30-35% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft...

    $695.00
  • Model SG 1-1/4" 316SS
    1-1/4" Model SG in 316SS Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure Recovery: 15-20% Maximum Suction Lift: -20ft. Maximum Required NPSH: 13ft...

    $695.00
  • Model SL 1-1/4" 316S
    1-1/4" Model SL in 316SS Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery: 10-15% Maximum Suction Lift: -27ft. Maximum Required NPSH: 3ft...

    $695.00
  • Model ULJ 1-1/4" 316SS
    1-1/4" Model ULJ in 316SS Maximum Temperature Rise: 200°F Maximum Flow Heated: 700 GPM Steam Pressure Range: 0-150...

    $695.00
