Replace Penberthy

Replace your Penberthy Jet Pump with a Jet Pump that offers better performance.   Offering the newest ideas in eductor design and manufacture, ideas that provide real user benefits. They match Penberthy eductors in connection sizes & dimensions.  There is no need for repiping or resizing.  The product is supported by a knowledgable staff, large inventory and World Class Manufacturering.

While our competition design their eductors for nominal pressure ratings, we offer eductors designed and produced to meet rigorous ASME/ANSI specifications.  Offer ratings about 30% higher than most competitors.  300# ANSI rated providing material ratings as follows: 316SS: 720 psig @ 100 F | Carbon Steel: 740 psig @ 100 F | Bronze: 500 psig @ 100 F

Need Help ?  Give us a call: 201-419-6111  Extension 23 for our Jet Pump & Eductor Group.

PENBERTHY CROSS OVER TABLE

Penberthy Model: Replace with Model: Material of Construction:
Penberthy Model LL Model SL Carbon Steel Bronze 316SS
Penberthy Model LM Model ML Carbon Steel Bronze 316SS
Penberthy Model LH Model HL Carbon Steel Bronze 316SS
Penberthy Model GL Model SG Carbon Steel Bronze 316SS
Penberthy Model GH Model HG Carbon Steel Bronze 316SS
Penberthy Model HLM Model MLH Carbon Steel Bronze 316SS
Penberthy Model ELL Model MLE Carbon Steel Bronze 316SS
Penberthy Model RJ Model ULJ Carbon Steel Bronze 316SS
Penberthy Model CTE Model TLA Carbon Steel Cast Iron 316SS
Penberthy Model TME Model TLM Polypropylene PVDF



Select a material of construction to narrow your search:

  • Electroless Zinc Plating is now a standard on Carbon Steel units.  This results in improved corrosion inhibition, improved wearability and reduces flow friction.
    Size: 2" 150# RF ANSI Flanged in Carbon Steel Like Our New Finish?  Electroless Zinc Plating is now a standard on Carbon Steel units.  This results in improved corrosion inhibition, improved wearability and...

    $550.00
  • Model TLM 3/8" SS
    Size: 3/8" Male NPT in 316LSS CF3M Construction Size IPS   Pressure Difference, PSI 10 20 30 40 50 60 70 80 90 100 120 140   Motive Flow (GPM) 7.1 10.0 12.3 14...

    $125.00
  • Model HG 1/2" 316SS
    1/2" Model HG in 316SS Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Steam / Air Motive Pressure: 20-150 PSIG Pressure Recovery:...

    $333.00
  • Model HG 1/2" BRZ
    1/2" Model HG in Bronze Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Steam / Air Motive Pressure: 20-150 PSIG Pressure Recovery:...

    $263.00
  • Model HG 1/2" CS
    1/2" Model HG in Carbon Steel Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Steam / Air Motive Pressure: 20-150 PSIG Pressure...

    $160.00
    Choose Options
  • Model HL 1/2" 316SS
    1/2" Model HL in 316SS Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Liquid Motive Pressure: 15-250 PSIG Pressure...

    $333.00
  • Model HL 1/2" BRZ
    1/2" Model HL in Bronze Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Liquid Motive Pressure: 15-250 PSIG Pressure...

    $263.00
  • Model HL 1/2" CS
    1/2" Model HL in Carbon Steel Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Liquid Motive Pressure: 15-250 PSIG Pressure...

    $160.00
    Choose Options
  • Model ML 1/2" BRZ
    1/2" Model ML in Bronze Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Liquid Motive Pressure: 15-250 PSIG Pressure...

    $263.00
  • Model ML 1/2" CS
    1/2" Model ML in Carbon Steel Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Liquid Motive Pressure: 15-250 PSIG Pressure...

    $160.00
    Choose Options
  • Model MLH 1/2" CS
    1/2" Model MLH in Carbon Steel Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT  Performance Details: Maximum Temperature Rise: 215°F Maximum Flow Heated: 5000...

    $160.00
    Choose Options
  • Model SG 1/2" 316SS
    1/2" Model SG in 316SS Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure...

    $333.00
  • Model SG 1/2" BRZ
    1/2" Model SG in Bronze Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure...

    $263.00
  • Model SG 1/2" CS
    1/2" Model SG in Carbon Steel Motive Connection: 3/8" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Steam / Air Motive Pressure: 15-250 PSIG Pressure...

    $160.00
    Choose Options
  • Model SL 1/2" 316SS
    1/2" Model SL in 316SS Motive Connection: 1/4" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery:...

    $333.00
  • Model SL 1/2" BRZ
    1/2" Model SL in Bronze Motive Connection: 1/4" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery:...

    $263.00
  • Model SL 1/2" CS
    1/2" Model SL in Carbon Steel Motive Connection: 1/4" MNPTSuction Connection: 1/2" MNPTDischarge Connection: 1/2" MNPT   Performance Details: Motive: Liquid Motive Pressure: 15-250 PSIG Pressure Recovery:...

    $160.00
    Choose Options
  • Model TLA 3/4" CS
    Size: 3/4" Male NPT in Carbon Steel Like Our New Finish?  Electroless Zinc Plating is now a standard on Carbon Steel units.  This results in improved corrosion inhibition, improved wearability and reduces flow...

    $79.00
  • Electroless Zinc Plating is now a standard on Carbon Steel units.  This results in improved corrosion inhibition, improved wearability and reduces flow friction.
    Size: 3/4" 150# RF ANSI Flanged in Carbon Steel Like Our New Finish?  Electroless Zinc Plating is now a standard on Carbon Steel units.  This results in improved corrosion inhibition, improved wearability and...

    $324.70
  • Model TLM 1" SS
    Size: 1" Male NPT in 316LSS CF3M Size IPS   Pressure Difference, PSI 10 20 30 40 50 60 70 80 90 100 120 140 1" mnpt Motive Flow (GPM) 16.1 19.7 27.0 32 36 37...

    $230.00
